In the below NVIDA specification sheet for interconnects:

  1. ACC mentioned at the top.
  2. Scroll down to 80% of the specification sheet (highlighted with underline) and you can see that manufacturing site is at Volex (China & Indonesia).

Info from NVIDIA product sheet;

Skip to end of banner

Go to start of banner

On This Page

Absolute Maximum Specifications

Absolute maximum ratings are those beyond which damage to the device may occur.

Prolonged operation between the operational specifications and absolute maximum ratings is not intended and may cause permanent device degradation.

Absolute Maximum Ratings

ParameterMinMaxUnits
Supply voltage-0.33.6V
Data input voltage-0.33.465V
Control input voltage-0.33.6V

This table shows the environmental specifications for the product.

Environmental Specifications

ParameterMinMaxUnits
Storage temperature-4085°C

Operational Specifications

This section shows the range of values for normal operation.

Operational Module Information

ParameterMinTypMaxUnits
Supply voltage (Vcc)3.1353.33.465V
Power consumption:
HDR 200Gb/s end
HDR100 100Gb/s end





3.5
2.5

W
W
Operating case temperature070°C
Operating relative humidity585%

EEPROM QSFP56 Memory Map I2C Address A0h

Page 00h/
Dec. Byte Address
Register NameDescription
0Identifier11h: QSFP+ or later with SFF-8636 or SFF-8436 management interface
1Status08h: Support for SFF-8436 Rev. 2.8 and 2.9
113Far End and Near End Implementations200Gb/s side (single 4x port):
50h: 2 far ends with 2 channels implemented in each (i.e., 2×2 break out); Channels 1-4 implemented on near end.100Gb/s side (dual 2x ports):
1Ch: Cable with single far end with 4 channels implemented; Channels 1 & 2 implemented on near end.
128Identifier11h: QSFP+ or later with SFF-8636 or SFF-8436 management interface
129Extended IdentifierCCh: Power Class 4, Tx/Rx CDR implemented
130Connector23h: No separable connector (cable assembly with no separable interfaces)
139Code for Serial Encoding Algorithm08h: PAM4
146LengthLength in units of 1 m: According to SFF-8636 section 6.3.12 Length: “For modules with non-separable media interfaces, this field specifies the link length of the cable assembly (copper or AOC) in units of 1 meter. Link length is as specified in the INF-8074 specification. Link lengths less than 1 meter shall indicate 1 meter.”
147Device technologyC0h: Copper cable, near and far end limiting active equalizers
148-163Vendor nameNVIDIA: ASCII
164Extended Module Codes for InfiniBand31h: Supports HDR / EDR / SDR
165-167QSFP vendor IEEE number00-02-C9: NVIDIA OUI.
168-183Part numberPart number per backshell label (ASCII)
184-185Product revisionZZ: Revision per backshell label (ASCII)
186-189Attenuation0h: Not used
190Max case temperature46h: Support for 70ºC
196-211Serial numberMTYYWWTTZZZZZ: Serial number per backshell label (ASCII).
212-217Date codeYYMMDD: Year YY, month MM, day DD.
222Signaling rate6Ah: Nominal baud rate per channel, units of 250 MBd.
237Wire gaugeWire thickness information.
1Eh: 30AWG

Mechanical Specifications

Table 7: Cable Mechanical Specifications 200/100G Sides

OPNLength (m)AWGCable DiameterMinimum Bend RadiusCable Color
MCA7J50-H003R3 ±0.050305.2 ±0.3 mm
Jacket: Thermoplastic copolymer (FRNC) BK
Single bend: 26mm
Assembly/repeated bend: 52mm
Black
MCA7J50-H004R4 ±0.050
MCA7J50-H005R5 ±0.050

The minimum assembly bending radius (close to the connector) is 10x the cable’s outer diameter. The repeated bend (far from the connector) is also 10x the cable’s outer diameter. The single bend (far from the connector) is 5x the cable’s outer diameter.

Assembly Bending Radius

Pull-tab Color Specifications

Single 200Gb/s QSFP56 Side
HDR Port: Yellow pull-tab
Hex = #ffd100
RGB = 255, 209, 0
CMYK = 0, 9, 100, 0
Pantone = 109 C
Double 100Gb/s QSFP56 Side
HDR100 Port #1: Red pull-tabHDR100 Port #2: White pull-tab
Hex = #ef3340Hex = #f4f5f0
RGB = 240, 61, 37RGB = 244, 245, 240
CMYK = 0, 86, 63, 0CMYK = Not available
Pantone = 032 CPantone = 11-0601 TCX (Bright White)

Mechanical Dimensions [mm] and Cable Length (L) Definition

Note: Color of pull-tabs is not shown in the grayscale illustrations below.

Connectivity Schematic

200Gb/s Side2x100Gb/s Side
Port 1 Red
TX1RX1
RX1TX1
TX2RX2
RX2TX2
Port 2 White
TX3RX1
RX3TX1
TX4RX2
RX4TX2

Label

The following figures show examples of the labels applied on the transceivers’ backshells.

Backshell Label – IB HDR 200Gb/s QSFP56 Side

  (sample illustration)

Backshell Label – IB HDR100 100Gb/s QSFP56 Side

  (sample illustration)

Backshell Label Legend

SymbolDescriptionNotes
PN – Part Number
xxLengthMeter
RRainbowColored pull tabs
SN – Serial Number
MTManufacturer name2 characters MT
YYYear of manufacturing2 digits
WWWeek of manufacturing2 digits
TTManufacturer site2 characters:VS: Volex ChinaVB: Volex Indonesia
ZZZZZSerial number5 digits for serial number. Reset at start of week to 00001.
Rev and other items
ZZHW revision2 alpha-numeric characters
XmCable lengthMeter
YYYY-MM-DDYear-month-dayYear 4 digits, month 2 digits, day 2 digits
COOCountry of originFor example: China, Indonesia
Quick response codeSerial number

The following label is applied on the cable’s jacket:

Cable Jacket Label

The following labels are applied on the cable’s jacket at the tail:

Note: The serial number and barcode are for internal use only.

  (sample illustration)

Splitter Copper Cable Labels Identifying the Tails

  (sample illustration)

Splitter Copper Cable Label Defining the Data Rate of Each Tail

   (sample illustration)

Regulatory Compliance and Classification

  • Safety: CB, UL, CE, EAC
  • EMC: CE, FCC, ICES, RCM, VCCI, EAC

Ask your field engineer or NVIDIA support for a zip file of the certifications for this product.

FCC Class A Notice

Each of the devices complies with CFR47 FCC Class A Part 15 of the FCC Rules. Operation is subject to the following two conditions:

  1. This device may not cause harmful interference.
  2. This device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur during installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

  • Reorient or relocate the receiving antenna.
  • Increase the separation between the equipment and receiver.
  • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
  • Consult the dealer or an experienced radio/television technician for help.

Modifications: Any modifications made to this device that are not approved by NVIDIA may void the authority granted to the user by the FCC to operate this equipment.
